All-Geared Universal Milling Machine ADM

All-Geared Universal Milling Machine ADM

MILLING

Model No

ADM 1232A
ADM 1332A

Get A Quote

Technical Specifications

Model	Unit	ADM 1232A	ADM 1332A
Table Size	mm	1250x320	1370x320
T Slot	no	3/14/70	3/14/70
Max. Load Of Table	kg	200kgs	200kgs
Table Longitudinal Travel (Manual / Auto) X	mm	620mm	740mm
Table Cross Travel (Manual / Auto) Y	mm	275mm	275mm
Table Vertical Travel (Manual / Auto) Z	mm	410mm	410mm
Spindle Taper		ISO40	ISO40
Spindle Speed (Vertical)	rpm	8/90-2000rpm	8/90-2000rpm
Horizontal	rpm	12/40-1300rpm	12/40-1300rpm
Max. Drilling Diameter	mm	30mm	30mm
Max. End Milling Width	mm	100mm	100mm
Max. Vertical Milling Dia	mm	25mm	25mm
Max. Tapping Dia		M16	M16
Quill Travel	mm	120mm	120mm
Swivel Angle of Headstock	degree	±45°	±45°
Vertical Spindle Axis To Column Surface	mm	200-700mm	200-700mm
Vertical Spindle Axis To Table Surface	mm	95-500mm	95-500mm
Longitudinal / Cross Feed (X, Y)	mm	22-555 / 8 steps	22-555 / 8 steps
Vertical Feed / Step (Z)	mm / Steps	540 / 8 Steps	540 / 8 Steps
Spindle Quill Feed		Manual + Auto	Manual + Auto
Main Motor	kw	2.2	2.2
X, Y & Z Axis - Feed Motor	kw	0.37	0.37
Coolant Motor	kw	0.04	0.04
N/W	Kgs	1550 kgs	1600 kgs

*Specifications are subject to changed without prior notice.

Accessories

Standard :

3Axis DRO for X, Y & Z Axis
Horizontal Milling Arbor Dia.22 And 27
Coolant Pump With Fittings
Milling Collet Chuck Set - 8 Pcs.
Drill Chuck Ø 16mm

Spindle Arbor ISO-40/B16
Draw Bar
Up/Down Hand Wheel
Tol Box
Milling Machine Vice 6" (Swivel base)

Optional :

Boring Head
Rotary Table Horizontal & Vertical (With Indexing Device)
Angle Plate

Photo Gallery

Box Cross Guide Way

Control Panel with DRO

X/Y Axis Feed Gear Box

Vertical Motorized Travel

Longitudinal & Cross Feed Motor

Lubrication Pump

3 Axis DRO

Coolant Pump

ADM 1232A

Videos

All Geared Universal Drilling & Milling Machine Model ADM 1232A
