Heavy Duty Slotting Machine(Heavy Duty)

Model : BHS-6,...
Heavy Duty Slotting Machine(Heavy Duty)
MODEL BHS-6 BHS-8 BHS-10 BHS 10-13 BHS-12 BHS-14 BHS-16 BHS-18
Stroke 6" 8" 10" 10 to 13" 12" 14" 16" 18"
Rotary Table 11" 13" 15" 18" 20" 20" 20" 24"
Longitudinal Movement 8" 10" 12" 12" 14" 16" 18" 18"
Cross movement 6" 8" 10" 10" 12" 14" 15" 16"
Cutting Speed of Ram per Minute 60-90 60-90 40-60 40-60 40-60 40-60 20-50-80 20-50-80
Ram Adjustment 8" 10"   12" 14" 16" 18" 18"
Throat Depth 12" 14" 18" 18" 20" 20" 21" 21"
Main Motor Power 1 HP 2 HP 2 HP 2 HP 2 HP 3 HP 3 HP 3 HP
Distance from the tool to Main column 10" 12" 15" 15" 18" 18" 19" 19"
