Bending / Press Brake Machines

Folding Machine

SHEET METAL

Model No

PBB 1020/2.5
PBB 1270/2.0
PBB 1520/1.5
PBB 2020/1.2
PBB 2520/1.0

Technical Specifications

Model	PBB 1020/2.5	PBB 1270/2.0	PBB 1520/1.5	PBB 2020/1.2	PBB 2520/1.0
Maximum Working Length	1020mm	1270mm	1520mm	2020mm	2520mm
Maximum Sheet Thickness	2.5mm	2.0mm	1.5mm	1.2mm	1.0mm
Maximum Clamping Bar Lift	47mm	47mm	47mm	47mm	47mm
Folding Angle	0-135°	0-135°	0-135°	0-135°	0-135°
Packing Dimension	1460x620x1270mm	1700x710x1270mm	1960x710x1300mm	2470x940x1320mm	2970x940x1320mm
Net Weight	285Kgs	320Kgs	385Kgs	490Kgs	590Kgs

*Specifications are subject to changed without prior notice.

Features

A Fully Welded Structure.
Compact High Quality Engineering.
Ensure Minimum Maintenance, Together With Simple and Safe Operation.
With Foot Control. It Is Easy For Operation And Relax Hands.
With foot control, it is easy for operation and relax hands for adjusting the material.
They have the function of air spring which can be installed inside the arm (Optional).
The press blade and folding blade are segment structure.
A fully developed quick release system for the clamp beam segment ensur fast interchangeability.
The folding beams are fitted with a counter balance and angle stop to provi a perfect and effective operation within the full capacity of the machine.
The optional back-guage can be easily mounted when using the pre-drilled fixing points.

Photo Gallery

PBB 1020/2.5

PBB 1020/2A

PBB 1020/3SH
