Pitch Controlled Tapping Machine (GearType)

Model : BT-50, BT-80

Technical Specifications

Photos Gallery

Model		BT-50			BT-80
Specification	FL	BM	FB	FL	BM	FB
Max. Tapping Capacity		M 10			M 16
Spindle Taper		JT2/JT2a			MT3
Spindle Travel		45			65
Spindle rpm / 35		420 760 1340			155 285 515
Swing		360			460
Column Diameter	80	52	80	102	85	102
Table Diameter	320	-	-	420	-	-
Base Size	330x510	330x510	320x400	390x580	390x580	400x500
Dist From Spindle To Table Max	350	380	-	530	470	-
Min	-	-	-	-	-	-
Dist From Spindle To Base Max	600	-	500	840	-	850
Min	-		200		-	200
T-Slot Size		IS 14	IS 14		IS 14	IS 14
No.ofT-Slot	-	2	2	^J-	2	2
Dist. between Two Slots	-	200	200	-	250	250
Motor HP		1			2
Overall Height	1100	930	2000	1500	1130	2300
Weight (Kg)	200	150	280	370	325	460
