Screw Tap Re-Sharpener (Y3C)

Model : Y3C,Y5C

Description

Technical Specifications

Parts

Photos Gallery

Portable screw tap grinder can grind 2-flute, 3-flute, 4-flutc tap. Choosing can grind 5-flute.
Y3C/Y5C can grind all front cutting face, also include the front cutting lip.
Standard equipment: Y3C six collets(Φ5-Φl4); Y5C nine collets(Φ13 -Φ30).
Standard grinding range; Φ-M20 ; Φ-M42
The thickness for the Y3C standard grinding wheel is 3mm.
Standard Collet Model No : Y3C (ER20) 6 Pes : 5,7,8,9,13,14.
Standard Collet Model No : Y5C (ER40) 9 Pes : 13,14,16,18,20,23,25,28,30.
Grinding Wheel: CBN Wheel For HSS Drill Bit / SD Wheel for Carbide Drill Bit.
