Hydraulic Autofeed Drilling Machine

Model : BH-5100,...

Technical Specifications

Photos Gallery

MODEL	BH-5100	BH-6150	BH-7150	BH-9150
Specification	FB	FB	FB	FB
Max. Drilling Capacity	Φ10	Φ 16	Φ 25	Φ 35
Spindle Taper	JT6	MT2	MT3	MT4
Spindle Travel	100	150	150	150
Spindle rpm / 35	1000.2000.3000	1000.1500.2000	500.1000.1500	100.200.300
Variable Speed	-	-	-	-
Swing	360	460	460	520
Column Diameter	80	102	102	115
Base Size	400x300	500x340	500x340	700x500
Distance From Spindle To Base	100-500	100-700	100-700	350-700
Hydraulic Pressure (Kg/cm2)	20	20	20	20
Motor HP	1	2	2	3
Overall Height	1800	2100	2100	-
Weight (Kg) approx.	260	380	600	1200
