Manual Feed Drilling Cum Tapping Machine

Model : LGT-340B,...

Technical Specifications

Photos Gallery

Model	LGT-340B	LGT-340A	LGT-550B	LGT-550A
Specifications	FL	FL	FL	FL
Max. Drilling Capacity	Φ13	Φ 20	Φ 25	Φ 25
Max. Tapping Capacity	M6	M 10	M 14	M18/M20*
Spindle Taper	MT2	MT2	MT3	MT3
Spindle Travel	80	100	120	140
Spindle rpm	520-2230	190-2840	230-1910	230-1910
Number of Speed	4	9	9	9
Swing	360	360	360	460
Column Diameter	80	80	92	102
Table Diameter	360	360	400	420
Base Size	300x500	300x500	335x580	380x600
Dist. From Spindle To
Table Max.	450	450	720	630
Dist From Spindle To Base
Max.	620	620	920	930
Min		_	__
Motor HP	0.5	1	1.5	2
Overall Height	1070	1070	1500	1540
Weight	75	90	140	190
