Mechanical Auto-Feed Drilling Machine

Model : LG-120, LG-250

Technical Specifications

Photos Gallery

Model	LG-120			LG-250
Specification	FL		FB	FL		FB
Max. Drilling Capacity		Φ16			Φ 25
Spindle Taper		MT2			MT3
Spindle Travel		100			140
Spindle rpm		470-1750			250-2500
Number of Speed		4			6
Swing		360			460
Column Diameter		80			102
Table Diameter	320		-	420		-
Base Size	300x500		400 x 320	380x600		500 x 400
Dist. From Spindle To Table (Max)	400		-	630
Dist. From Spindle To Base (Max)	600		500	930		800
(Min)	-		200	-		200
T-Slot Size	-		IS 14	-		IS 14
No.of T-Slot	-		2	-		2
Dist. between Two Slots	-		200	-		250
Motor HP		1			2
Overall Height	1050		1600	1600		2300
Weight ( Kg) approx.	100		220	220		270
