Shaping Machine (Standard Model)

Model : TCS-12,...

Technical Specifications

Features

Photos Gallery

Model	TCS-12	TCS- -18	TCS-24	TCS - 30	TCS - 36
Machine size	12"	18"	24"	30"	36"
Maximum stroke	14"	20"	26"	32"	38"
Len of Ram	26"	36"	50"	58"	66"
Max. dist. of Table to Ram	9"	15"	19"	20"	20"
Min. dist. of table to Ram	½”	2"	2"	2"	2"
Max. vertical travel to tool slide	5"	4"	7"	7"	7"
Length & width of table top.	12" x 9"	18" x 12 "	24"x 15"	30.1/2" x 16"	36" x 18"
Length & width of table slide	24" x 10"	30" x 11 "	37.1/2" x 12"	44"x 13"	48" x 14"
Length of cross slide	24"	30"	37.1/2"	44"	48"
Width of Ram	8.1/2"	10"	12.1/2"	12.1/2"	13"
No of speeds	4	3	4	4	4
Main Motor Power	1 HP	2 HP	2 HP	3 HP	5 HP
