Single Head Hydraulic Pipe Bending Machine (NCB Series)

Single Head Hydraulic Pipe Bending Machine (NCB Series)
PIPE BENDING

Model No

  • NCB38
  • NCB50
  • NCB63
  • NCB75
  • NCB89
  • NCB100
  • NCB110
  • NCB115
  • NCB130
  • NCB168
  • NCB189
  • NCB219

Technical Specifications

Model NCB38 NCB50 NCB63 NCB75 NCB89 NCB100 NCB110 NCB115 NCB130 NCB168 NCB189 NCB219
Max bending capacity diameter x thickness mm 038 x 2 050 x 3 063 x 4 075 x 4 089 x 8 100 x 8 Ø110 x 8 Ø115 x 10 Ø130 x 8 Ø168 x 14 Ø189 x 14 Ø219 x 16
Max bending radius (1) mm R260 R350 R350 R400 R450 R500 R500 R520 R520 R750 R750 R800
Min bending radius (2) mm According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter According to the Pipe Diameter
Max bending angle Degree 190° 190° 190° 190° 190° 190° 190° 190° 190° 190° 190° 190°
Max effective distance of mandrel (3) mm 1600 2200 2600 2800 3500 3600 3700 4500 4500 5000 5500 6000
Control System Unit NC Control NC Control NC Control NC Control NC Control NC Control NC Control NC Control NC Control NC Control NC Control NC Control
Max bending groups groups 16 16 16 16 16 16 16 16 16 16 16 16
Max storing components (4) Kw 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16 16 x 16
Motor Power Mpa 4 5.5 5.5 7.5 11 15 14 14 14 16 16 16
Max. Hydraulic Pressure 12 12 12 12 12 12 12 12 12 12 12 12
Hydraulic System Control L Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve Electromagnetic Valve
Oil Tank Capacity mm 110 150 220 250 260 300 320 350 400 650 700 800
Machine Size kg 2600x600x1000 3000x700x1030 3500x700x1100 4000x1000x1100 4500x1300x1300 5000x1600x1200 5000x1400x1200 5500x1600x1200 6100x1600x1300 7100x2000x1800 8000x1800x1660 8800x2450x1980
Weight Of Machine 750 1220 1500 2000 3500 5000 4500 7000 8000 12000 15000 20000

Note: (1) (3) According to customer’s requirements, (2) According to tube diameter, (4) Extendible

*Specifications are subject to changed without prior notice.

Features

  • Use high function imported Japan Yuken hydraulic components.
  • Have big capacity cooling system and can control the working temperature.
  • The machine is NC control, hydraulic drive, can have different bending degree to prefabricate.
  • The machine have easy convenient, stable function, high efficiency, high safety factor, is the ideal choice for the pipe processing.
  • English display screen, Man-machine dialogue operation. Can choose manual, semi-automatic, portable pedal have start, emergency stop function.
